| Application | 2-Axes Position Monitoring and Leveling |
| Measurement Range | ± 30° |
| Accuracy (INL) | ±0.02° |
| Resolution | 0.01° |
| Supply Voltage | 10 – 30 VDC |
| Current Consumption | ≤ 100 mA @5V, ≤ 45 mA @10V, ≤ 25 mA @24V |
| EMC: Emitted Interference | DIN EN 61000-6-4 |
| EMC: Noise Immunity | DIN EN 61000-6-2 |
| Reverse Polarity Protection | Yes |
| Short Circuit Protection | Yes |
| MTTF | 300 years |
| Storage Temperature | -40 °C (-40 °F) – +85 °C (+185 °F) |
| Temperature Gradient | 0.003°/ K |
| Storage Temperature | -40 °C (-40 °F) – +85 °C (+185 °F) |
| Temperature Gradient | 0.003°/ K |
| Protection Class (Housing) | IP66/IP67 |
| Shock Resistance | ≤ 300 g (half sine 6 ms, EN 60068-2-27) |
| Vibration Resistance | 10 – 150 Hz, 2.5 mm amplitude, 5 g const. Acceleration |
| Min Temperature | -40 °C (-40 °F) |
| Max Temperature | +85 °C (+185 °F) |
| Housing Material | Aluminum |
| Weight | 370 g (0.82 lb) |
| Interface | CANopen |
| Transmission Rate | min. 20 kBaud, max. 1 MBaud |
| Default Transmission Rate | 20 kBaud |
| Default Node ID | 20h |
| Connection Type | Connector M12 (8 pin) |
| Connector | M12, Male, 8 pin, a coded |
| Product Life Cycle | Discontinued |
